Pompa, Havalandırma, Fan / PUMPS & FANS & WPS

HİDROFORLAR
WATER PRESSURE SYSTEMS
HYDRO-EC

ELEKTRONİK KONTROLLÜ HİDROFOR / Electronic Controlled WPS
ÖLÇÜLER H mm D mm W mm Kg
POMPA GÖVDESİ / BODY PUMP
HEC 1 DC 370 440 240 9
DÖKÜM HEC 2 DC 370 440 240 10
PERVANE / IMPELLER HEC 2 AC 370 440 240 9
HEC 4 DC 400 600 270 23
TECHNO POLYMER
HEC 4 AC 400 570 270 22
ŞAFT / SHAFT HEC 5/18 DC 450 740 270 31
PASLANMAZ ÇELİK / STAINLESS STEEL HEC 5/18 AC 450 680 270 30
HEC 1 DC 12 - 24 45 2.6 0.30 1” 1”
HEC 2 DC 24 48 3.4 0.37 1” 1”
HEC 4 DC 24 85 3.4 0.75 1” 1”
HEC 5/18 DC 24 95 4.5 1.10 1¼” 1”
HEC 2 AC 1~230 - 3~230/400 48 3.6 0.37 1” 1”
HEC 4 AC 1~230 - 3~230/400 70 4.0 0.75 1” 1”
HEC 5/18 AC 1~230 - 3~230/400 95 4.5 1.10 1¼” 1”
Voltage V Max Delivery l/min Max Pressure bar Power kW IN - OUT
HYDRO-PRESS

HİDROFOR / Water Pressure Systems

ÖLÇÜLER H mm D mm W mm Kg
POMPA GÖVDESİ / BODY PUMP
HPI 2 DC 580 600 280 20
DÖKÜM HPI 2 AC 580 600 280 19
PERVANE / IMPELLER HPI 4 DC 600 600 280 33
TECHNO POLYMER HPI 4 AC 600 600 280 32
ŞAFT / SHAFT
PASLANMAZ ÇELİK / STAINLESS STEEL
SU TANKI / WATER TANK
PASLANMAZ ÇELİK BOYALI /
PAINTED STEEL WITH FLANGE AISI 316
HPI 2 DC 24 48 3.4 0.37 1” 1”
HPI 4 DC 24 85 3.4 0.75 1” 1”
HPI 2 AC 1~230 - 3~230/400 48 3.6 0.37 1” 1”
HPI 4 AC 1~230 - 3~230/400 70 4.0 0.75 1” 1”
Voltage V Max Delivery l/min Max Pressure bar Power kW IN - OUT

HYDRO-A

KOMPAKT SU BASINÇ SİSTEMİ - HİDROFOR / Compact Water Pressure Systems
ÖLÇÜLER H mm D mm W mm Kg Liter
POMPA GÖVDESİ / BODY PUMP
HA 60 DC 240 300 180 10 2
BRONZE HA 60 DC 425 355 230 13 5
PERVANE / IMPELLER HA 60 AC 425 355 230 13 5
BRONZE HA 80 DC 350 410 170 18 2
ŞAFT / SHAFT
PASLANMAZ ÇELİK / STAINLESS STEEL
SU TANKI / WATER TANK
2L & 5L PASLANMAZ ÇELİK BOYALI /
PAINTED STEEL WITH FLANGE AISI 316
HA 60 DC 12 - 24 19 2 0.18 ½” ½”
HA 80 DC 12 - 24 48 3.3 0.37 ¾” ¾”
HA 60 AC 1~230 14 2 0.15 ½” ½”
Voltage V Max Delivery l/min Max Pressure bar Power kW IN - OUT

TF MARINE / Su Basınç Sistemleri - Hidroforlar 79
