Pis Su Arıtma Sistemi / WASTE WATER TREATMENT SYSTEMS

sewage treatment systems

Yeni nesil BlueSea Arıtma Sistemi günde 2500 ile 22000 litre aralığında
modelleri olan atıksu arıtma sistemidir.

BlueSea siyah ve kirli suyu arıtmak için Ozon, Free Radical OH, Ultraviyole
ışınlar ve Hidrojen peroksitten oluşan kombine bir sistem kullanır.
Bu tamamen otomatik, teknolojik olarak gelişmiş sistem, atık suyun denize
boşaltılmasına ilişkin yürürlükteki normlara uygun olarak atık suyun
prüzyona tabi tutulduğu, toz haline getirildiği, steril edildiği özel bir
kimyasal / fiziksel laboratuvar ile donatılmıştır.

BlueSea atık su arıtma sistemi, bir oksit / indirgeme işlemi vasıtasıyla
bakteriyel kirliliğin giderilmesini garantilemekte ve en önemlisi, tekne
üzerinde üretilen atık sudaki TSS, BOD5, COD, turbitidiyi ve organik ve
fiziksel kirleticileri büyük ölçüde azaltmaktadır.

The BLUE SEA system is a new-generation waste water purifier capable of treating from 2500 to 22000 litres a day. This completely automatic, techno-
logically advanced system is equipped with a special chemical/physical laboratory where waste water is purified, triturated, sterilized, all in accordance
to the enforced norms regarding the discharge of waste water into the sea. In fact, a BLUE SEA waste water treatment system guarantees the elimination
of bacterial pollution through an oxide/reduction process and, most of all, drastically reduces TSS, BOD5, COD, turbidity and the organic and physical
pollutants in waste water produced on boat thanks to a fine purification system. With BLUE SEA it is now possible to discharge waste weater directly into
the sea with full respect for the environment and compliance with current standards, at the same time avoiding heavy and inconvenient waste collection
tanks and long drainage procedures in authorized ports. BLUE SEA series purifiers are compact and assembled on a solid stainless steel structure that
guarantees the maximum reliability and long life; because of their small size and versatility, compared to traditional systems, they can be installed in all
applications where the available space is limited. The menagement of the system and the various purification steps are handled by a latest-generation
PLC that coordinates and constantly monitors its operations. The unit allows the user to control all its operating parameters, making control of its
plumbing and electrical systems simple.

Standart Özellikler Aksesuarlar
• Otomatik yıkama sistemi • Macerator pis su pompası
• Likit oksit tank • Deniz suyu pompası
• Elektronik taşma kontrolü • Hava Filtresi (Aktif Karbon)
• Mekanik taşma kontrolü • İkincil arıtma için U.V Sterilizör
• Saat Sayacı • LCD Panel uzaktan kumanda
• Kontrol üniteli Primer "U.V STERİLİZASYON” merkezi • Anti-sifon Valf
• Havalandırma • Yağ Kapanı
• Çevrim Sayacı
• Teknenin tankı için mekanik minimum seviye sensörü ve montaj kiti
• Cihazın kontrolü ve yönetimi için Operatör paneli ve LCD ekran

EC Type Examination Certificate
Notified Body 2843

This is to certify that ABS ITALY S.R.L. did undertake the relevant type approval procedures for the type
of equipment identified below which was found to be in compliance with the requirements of Marine
Confirmation of Product Type Approval Equipment Directive (MED) 2014/90/EU, subject to any conditions in the schedule attached hereto.
Company Name: SELMAR TECHNOLOGIES SRL ITEM NUMBER: MED/2.6b
Address: CONTRADA SAN SILVESTRO 452ZONA INDUSTRIALE 91025 Italy IMPLEMENTING REGULATIONS (EU) 2021-1158
Product: Sewage Treatment Plant
Model(s): BLUE SEA Models, BLUE SEA PLUS models C ERTIFICATE NUMBER: 21-2163091-EC
Certificate Type Certificate Number Issue Date Expiry Date MANUFACTURER: SELMAR TECHNOLOGIES SRL
Product Design Assessment (PDA) 20-2042150-PDA 28-OCT-2020 27-OCT-2025 MANUFACTURER’S LOCATION: Marsala, Italy
Manufacturing Assessment (MA) 20-4499748 29-OCT-2020 28-OCT-2025
Product Quality Assurance (PQA) NA NA NA
AUTHORIZED R EPRESENTATIVE: N/A
Tier
3 PRODUCT DESIGNATION: Sewage treatment plant
Intended Service
The equipment is intended for installation onboard ships to provide sewage treatment for the protection
of the marine environment. Shipboard Sewage Treatment Units, complying with IMO Resolution MEPC. S TANDARDS AND R EGULATIONS:
227(64) for ships other than passenger ships in all areas and passenger ships operating outside
MARPOL Annex IV special areas. European Union Marine Equipment Directive 2014/90/EU referencing testing
requirement of implementing regulation (EU) 2021-1158.
Description MARPOL 73/78 Annex IV, Reg. 9,
BLUE SEA models usea combined action of Ozone, Free Radicals OH-, ultraviolet rays and hydrogen IMO Res.MEPC.227(64) not including section 4.2

peroxide for the black and gray water treatment.
BLUE SEA Models 2500 / 3500 / 4000 / 7000 / 12000 / 22000, Include BLUE SEA PLUS models.
THIS CERTIFICATE IS ISSUED IN COMPLIANCE WITH CONFORMITY ASSESSMENT MODULE B OF THE REGULATIONS AND DIRECTIVES LISTED
Nominal AC power consumption is 1.3kW for all models.

ISSUE DATE: 31-aug-2021 E XPIRATION DATE: 30-aug-2026 MED-B-10006:
Ratings ELECTRONICALLY
Model Hydraulic Load (m^3/day) Organic Load (kg BOD5/day) SIGNED BY : E. Brina UNI EN ISO 9001:2008
This certificate will not be valid if the manufacturer makes any changes or modifications to the approved type of equipment, which have not been notified to, MED-D-1810 IMO Marpol
2500 2.5 1.29 and agreed with the notified body named on this certificate.

a
pp
ro

3500 3.5 1.81 Should the specified regulations or standards be amended during the period of validity of this certificate, the product(s) is/are to be reved prior to it/they
being placed on the market and on board vessels to which the amended regulations or standards apply.

4000 4.0 2.06 The “Mark of Conformity” may only be affixed to the above type approved equipment and a Manufacturer's Declaration of Conformity issued when the Mepc 227(64)
productioncontrol phase module (D, E, or F) of ANNEX B of the Directive is fully complied with and controlled by a written inspection agreement with a notified
body.
7000 7.0 3.61 This certificate remains valid unless suspended, expired or withdrawn, provided the conditions in the attached schedule are complied with.
The attached document schedule forms part of this Certificate.
12000 12.0 6.19
22000 22.0 11.35
ABS CERTIFICATE ABS CERTIFICATE
Conformity certificate UNI EN ISO 9001:2008
All sewage treatment systems BlueSea are certified by DNV-GL according to Product Design Assessment (PDA) 20-2042150-PDA
NEW RES. IMO MARPOL Mepc. 227(64) and New European Directive Manufacturing Assessment (MA) 20-4499748
2014/90/EU (MED).
No. Certificates: MED-D-1810 and MED-B-10006 Product Quality Assurance (PQA) NA
44 Blu Sea / Pis Su Arıtma Sistemi
